SRS Lighting | DSR10ABN | DMX splitter 10-channel | A|B line switch | 2 universe | DMX Input: RJ45 | DMX output: RJ45 | 19-inch | Power input: Powercon

DMX splitter 10-channel A and B line

This SRS Lighting DMX splitter 10-channel A- and B-line can control two lines of DMX. You can select per channel whether you want to use the A-line or the B-line. SRS Lighting's DMX splitters are of very high quality.

Voltage variations

All DMX splitters from SRS Lighting can be equipped with DMX 3- and/or 5-pin XLR and/or RJ45. All DMX splitters have a DMX input and DMX-thru. The DMX outputs are optically/electrically isolated lines and are marked with numbers. Each DMX output vhas a separate power supply and line driver, and a clear indication of the signal by means of two LEDs per output. The DMX splitters have a switched-mode power supply, allowing the mains voltage to vary between 85V and 265V. The specifications:

• 2 optically isolated inputs
• 10-channel DMX splitter with input (A/B) selection
• optically isolated outputs with 1000V isolation
• 2x led indication for DMX line status per output
• 2x LED indication for DMX line status per input
• 2x DMX end stop by switch
• mains power via powercon
• 19" 1he rack mount
• mains voltage, powercon 85-265V, 50/60Hz
• lifetime warranty!

On this DMX splitter 10-channel SRS Lighting gives a lifetime warranty!
