JB-Lighting | Sparx 7 | Washlight LED Moving Head | 19x15W RGBW | 4°–40° | 8 kg

JB-Lighting | Sparx 7 | LED Wash Moving Head | 19x15W RGBW | 4-40° | 8kg |

New and groundbreaking: the Sparx 7. It is immediately apparent that JB-Lighting is breaking new ground with its lens design. The design and arrangement of the lenses, with only small gaps between them, produce a circular beam.

The optical design highlights the state-of-the-art LED technology and is nothing short of a striking visual feature. The Sparx 7 is equipped with 19 multi-chip RGBW LEDs in the 15-watt category and naturally comes with the superior technology that also characterises the A8 and A12 wash lights. This includes, among other things, a unique cooling system that enables maximum power consumption at minimum noise levels, integrated wireless DMX and three-phase stepper motors for lightning-fast and precise movements. Another feature has been added to the wide range of control options: various layer patterns are available that can be freely combined for unlimited colour and pattern variations. This comes close to individual control, but requires only a fraction of the number of DMX channels. The Sparx 7 is a compact yet extremely bright wash light, meticulously designed with high-quality optics. A perfect wash light with extensive effect capabilities, always deserving a prominent place on stage. The sparkle channel creates a beautiful star-like effect that looks fantastic on camera.

Wireless DMX

The Sparx 7 comes as standard with a built-in receiver circuit for wireless DMX. It works with the Wireless TRX using JB-Lighting’s proprietary protocol.

Dimming

For over 10 years, JB-Lighting has been perfecting the dimming behaviour of LED wash lights. The Sparx 7 features the most advanced software in this field. The result is colour-accurate and flicker-free dimming. The Sparx 7 offers various dimming curves and a mode for tungsten-like dimming.

Maintenance

The Sparx 7, A8 and A12 are the only wash lights whose LEDs can be replaced without using a soldering iron. The individual LED modules simply click into place on a circuit board. In an emergency, this saves time and money.

LED control and sparkle effect

Unlimited colour and pattern variations are available by combining different layer patterns. This requires only a fraction of the DMX channels that would be needed to control the LEDs individually. Notable is the extra sparkle channel that creates fire and water effects and a beautiful star-like effect that looks fantastic on camera.

Colour mixing and patented optical system

At the heart of every wash light is the colour mixing. The Sparx 7 offers various options for mixing colours, which can be combined with patterns. There is a colour wheel channel, a CTC channel, glow channels for backlighting, a colour spread function and three independent sets of RGBW channels, all of which can be combined with the pattern section. And above all, the zoom range is 4°–40°.

Wireless TRX

The Sparx 7 is equipped with a built-in wireless DMX-in module and can be controlled wirelessly using JB-Lighting’s Wireless TRX without the need for additional accessories. The Sparx 7 can display the received signal strength on its display thanks to the built-in radio DMX module. The JB-Lighting Wireless TRX uses the 2.4GHz frequency band and can be used as a transmitter or receiver.

Omega bracket

The Sparx 7 is mounted using omega brackets with original Camloc connectors that can be locked without much force or the use of tools. There are 5 different rigging variations of the omega bracket to ensure that the fixture can be attached to any type of truss system without any problems. An omega bracket is available as an option for mounting with a single clamp

• Zoom 4°–40° (4°–30° at 1/2 peak, 8°–40° at 1/10 peak)
• Wireless DMX onboard
• 19 multi-chip LEDs 15W
• RGBW
• Weight 8kg
