DAP | D6152 | ZA-7250 | 250 W 100 V 4-Zone Mixer Amplifier
Description
The DAP PA-7250 is a 240-watt 100 V 4-zone mixer amplifier with 4 selectable sources and 3 microphone inputs. All microphone inputs are equipped with phantom power and can be selected as line input. An integrated speech filter can be applied to improve intelligibility. This mixer amplifier has 3 RCA inputs on the rear and an easy accessible line/phone input (Mini-Jack) on the front for connecting an MP3 player or mobile device.The PA-7250 has enhanced features. It has for example a special line for emergency announcements (such as a fire alarm) that will overrule all other inputs. It is also equipped with an adjustable chime function, ducking level control, loop through connection and a line output that can be set as line output, music only or microphone only. Besides, each zone also has its own line outputs for being able to connect extra amplifiers, allowing you to extend the PA system if needed.
This 100 V zone mixer amplifier is designed to support a PA system intended for intercommunication or background music in public and business areas such as convention halls, shopping malls, dining halls, auditoriums and recreational areas. It has an integrated protection circuit to protect against overload and short circuit of the output. This results in very high reliability and easy installations without the need for additional audio processors.
Technical specifications
Power Amplifier RMS Output: 250 W
Output Channels: 4
Output Mode: Parallel
Output Connector: Terminal
Main Outputs: 2
Main Output Connector: 3-pin XLR / RCA
Zone Outputs: 4
Zone Output Connector: Terminal / RCA
Mono Inputs: 3
Mono Input Connector: 3-pin XLR / Terminal / TS unbalanced 6.3 mm
Stereo Inputs: 3
Stereo Input Connector: TRS balanced 3.5 mm
Auxiliary Inputs: 1
Auxiliary Input Connector: RCA
Transformer: 100 V
Phantom Power: 18 V
Parametric Channel Equalizer: 2 Bands
Parametric Microphone Equalizer: 2 Bands
Speech Filter Attenuation: 3 dB
Speech Filter Frequency: 300 Hz
Power Supply: 240 VAC 50-60 Hz
Backup Power Supply: 24 VDC
Power Consumption: 517 W
Power Connector In: IEC
Height (mm): 88 mm
Width (mm): 483 mm
Depth (mm): 345 mm
Rack Units: 2 U
Weight: 12.8 kg
PTT: Yes
Chime: Yes
Telephone Input: Yes
Electronic Protection: Overload / Short circuit
